Wind power
Whether in hot, cold, dry, or “aggressive” saline environments – wherever wind power stations generate energy, we do everything to ensure that no energy is lost unnecessarily. We have developed specialty lubricants for this purpose which clearly contribute to reducing the wear on your equipment and thus significantly reduce your maintenance effort and expenditures. We offer low-temperature greases for arctic conditions, high-performance greases for long-term lubrication, or efficient specialty lubricants for pitch and yaw bearings – all for ideally smooth generation of energy with no loss of energy and with optimal frictional wear protection.
Special lubricant for pitch and yaw bearings (gear ring and bearing)
GLEITMO 585 K
GLEITMO 585 K is a well-proven, fully-synthetic special lubricant containing reactive white solid lubricants. This synergistic combination offers excellent protection against wear even under most critical operation conditions like vibrations and small oscillation movements under high load which are typical for pitch and yaw bearings of wind turbines. It is also used for gear lubrication of pitch and yaw bearings using lubrication pinions.
GLEITMO 585 K PLUS
GLEITMO 585 K PLUS has been developed in order to meet the requirements of novel lubrication systems. This lubricant is most suitable where progressive distributors are used. GLEITMO 585 K PLUS was developed on the basis of the original GLEITMO 585 K and the excellent wear-protection properties have been retained despite the adaptation of the product. The PLUS in the article name stands on the one hand for the added value gained and on the other for the use in Progressive LUbrication Systems.
- Extremely wide temperature range, suitable for any climate condition: -45°C up to +130°C
- Consistency: NLGI grade 2
- Identification according to DIN 51502: KPFHC2K-40
- Outstanding wear protection, especially at shock loads and oscillatory movements
- Excellent protection against standstill marks, fretting corrosion and tribocorrosion
- Rippling test (TK Rothe Erde / IME at RWTH Aachen) and swivelling rippling tests (ITR at TU Clausthal) passed; prevents and protects against standstill marking
- Suitable for Individual Pitch Control with changeable swivel angle (according to comparison test of IMKT, Hanover and Fraunhofer IWES)
- Extreme Pressure (EP) properties at low rotational speed
- Approvals: Rothe Erde (ThyssenKrupp), IMO, ZS Schmieranlagen
- References: manufacturers and operators of wind power plants and component manufacturers
Fully synthetic high-performance grease for pitch, yaw and rotor bearings
STABYL LX 460 SYN
STABYL LX 460 SYN is a fully synthetic high-performance grease which was especially developed for the use in wind turbines. Due to its wide operating temperature range, its high mechanical stability and its outstanding load carrying capacity, STABYL LX 460 SYN is excellently suitable for the lubrication of the main rotor bearings. Moreover, it can also be used as multifunctional grease in the very demanding lubricating areas of azimuth and pitch bearings because of its special properties. Therefore STABYL LX 460 SYN considerably reduces the necessary efforts for a safe grease supply in all these lubricating points.
- Universal application in wind turbines, especially for pitch, yaw and rotor bearings
- Extremely wide temperature range, from –40°C up to +140°C
- Consistency: NLGI grade 1-2
- Indentification according to DIN 51502: KPHC1-2N-40
- Reduction of lubricant diversity in wind turbines
- Excellent protection against standstill marks and fretting corrosion
- Pumpable in automatic lubrication systems
- Extreme pressure properties to protect against wear
High-performance grease for main bearings, pitch and yaw bearings
STABYL EOS E 2
STABYL EOS E 2 is a high-performance grease based on a fully-synthetic ester and a lithium soap. It fulfils the highest technical requirements for modern lubricants used in wind turbines. STABYL EOS E 2 was developed as multifunction grease in a perennial research project in cooperation with leading bearing manufacturers and is successfully in use in wind turbines as general purpose lubricant.
- Universal application in wind turbines, especially for pitch, yaw and rotor bearings
- Extremely wide temperature range, suitable for any climate condition: –45°C up to +130°C
- Consistency: NLGI grade 1-2
- Identification according to DIN 51502: KPE1-2K-40
- Allows considerable reduction of lubricant diversity on wind turbines
- Very good protection against false brinelling and fretting corrosion
- Extreme pressure properties at low rotational speed
- Pumpable in automatic lubrication systems
- Approvals: Rothe Erde (ThyssenKrupp), IMO, ZS Schmieranlagen
- References: manufacturers and operators of wind power plants and component manufacturers
Fully synthetic polyurea grease for extreme application conditions
URETHYN XHD 2
URETHYN XHD 2 is a soft lubricating grease with a synthetic hydrocarbon base oil and a very temperature-resistant polyurea thickener. A selected additive package provides excellent wear protection, even at fluctuating speeds, temperatures and loads.
- High-temperature lubricant for long-life lubrication of roller bearings at high temperatures, high loads, and speeds e.g. in generator bearings of wind turbines
- Temperature range: –40°C up to +180°C, short-term up to +200°C
- Consistency: NLGI grade 2
- Identification according to DIN 51502: KPFHC2R-40
- Extraordinary thermal stability
- High oxidation stability also during intermittent operation
- Pumpable in automatic lubrication systems
- References: manufacturers and operators of wind power plants, components and lubrication system manufacturers
White adhesive lubricant suitable for low temperatures
CEPLATTYN BL WHITE
CEPLATTYN BL WHITE is a white adhesive lubricant with reactive solid lubricants. It is used as a lubricant for machines and machine components operating under difficult conditions, subject to extreme temperature fluctuations and environmental influences. CEPLATTYN BL WHITE is used in particular for the lubrication of azimut and pitch gear rings in wind turbines.
- For lubricating of azimut and pitch gears
- Very wide temperature range: –40°C /+160°C, up to +180°C for a short time, pumpable down to –30°C
- Very good adhesion to the tooth flanks
- High thermal and mechanical stability
- Protects the gear ring against corrosion
- Very good water resistance, thus also unlimited suitability for off-shore turbines
- Pumpable in automatic lubrication systems
- References: manufacturers of slewing bearings and manufacturers of lubricating equipment
